• Standard range: 0-25%
Optional ranges: 0-1%, 0-5%, 0-10%, 0-50% or 0-100%
• Analog output signals: 0-2.5VDC for 0-25%  range
 0-2.5VDC output for optional measurement ranges:
 0-1%, 0-5%, 0-10%, 0-50%
 0-4.00VDC output for optional measurement range: 0-100%
 Note: Customer must supply span control function
• Power requirements: 10-28VDC <1 watt
• Minimum detection: 0.01% of oxygen
• Repeatability: +/- 0.2% of range or +/- 0.1% of
  oxygen, whichever is greater
• Operating temperature range: 32 to 115˚ F
• Diurnal temperature specification:
  < +/- 3 % of scale over temperature range
• 90% full scale response times for specified range:
  0-25% <10 seconds; 0-100% < 35 seconds
• Area Classification: Designed to meet General Purpose requirements
• Inlet gas pressure for models using flow-through style fittings:
 Standard barbed fittings:
 1.0 to 30psig recommended. User must supply flow
 control from 0.1 to 5.0 SCFH.
 Optional ¼” compression fittings: 1.0 to 30psig
 recommended. User must supply flow control from 0.1 to 5.0 SCFH.
 Optional diffusion screen: For area monitoring at atmospheric pressure
• Wetted parts: plastic barbed fittings, anodized aluminum body
• Unaffected by changes in flow rate from 0.1 to 5.0 SCFH
• Mounting: Wall mount with bracket
• Dimensions: 1.80” D. x 2.00”L
• Weight: <1 lbs.
